Optima HQ thermal CTP Plate is specifically designed for cost-conscious printers, who needs medium to long rung lengths with high-performance press quality. It uses advanced thermal plate technology to deliver 1-99% at 250 lpi resolutions, which will satisfy general commercial print qualty requirements. Manufactured with strict qualty control production procedures, OPTIMA HQ is able to provide printers excellent and reliable pre -press and print results.

Product specifications

Suitbale for                         : Medium to long run length commercial printing

Substrate                            : High quality grained and anodized aluminium

Maximum width               : 1480 mm

Spectral sensitivity          : 830 nm

Exposure energy              : 120-130 mj/cm²

Resolution                          : 1-99% @250 Ipi

Run length                          : 100.000 unbaked, 1.000.000 impressions when post-baked

                                                * Run length depends on processing and printing quality control and conditions.

UV ink compatibility        : Applicable with UV inks when post-baked

Shelf life                              : 18 months when stored away from excessive cold, heat and humidity.

Storage condition              : Store plates flat in their packaging, away from excessive cold, heat or high

                                                humidity at 5 C- 30 C, with RH between 40-80 %

Post baking recommend  : 230-250 C, 5-8 minutes
